Sotera 12V DC Diaphragm Pumps

Sotera 12V DC Diaphragm Pumps

Request more information about this product:

Description

Model R1415-X670

A high capacity 12VDC farm chemical dispensing pump, the Sotera Series 400 Dual Diaphragm Pump and motor unit is the same as that found in the widely used “Chemtraveller”, but in a format which can be hard-piped and wired into your boom spray system.

 The 400 Series “Bare” Pump incorporates:

  • Corrosion resistant glass-reinforced polypropylene pump with ‘Paraquat’ friendly wetted parts.
  • Santoprene diaphragms
  • The highest flow-rate in its class, with a maximum rate of 50 l/min, up to 28  l/min of Glyphosate or 35 l/min of Trifluralin (temperature & concentration dependent)
  • Maintains constant pressure regardless of load (max Working Pressure, 150 kPa
  • The ability to handle high viscosities (over 1000 cps) and particles up to 2.5mm
  • A proven 1/4 HP, 12V DC motor requiring just 16 amps under normal operating conditions, with Thermal Overload protection

 Optionally we can supply:

  • Micromatic Stainless Steel FCC Coupler and Rinsing Socket (depending on model)
  • 2.85 Metre reinforced suction hose and 4 Metre discharge hose
  • Poly ball valve and anti-drip nozzle

 Also available as part of the “Chemtraveller” dispensing package

Brand

Sotera
